LX10
LX10
| REF. | CCT(K) | lm/m | lm/W |
| LX10-23 |  2300K |
1180 | 118 |
| LX10-27 |  2700K |
1290 | 129 |
| LX10-30 |  3000K |
1360 | 136 |
| LX10-40 |  4000K |
1390 | 139 |
| LX10-60 |  6000K |
1430 | 143 |
Features
| Power | 10 W/m |
| Power per 5 m roll | 24 W |
| IP | 67 |
| CRI | >90 |
| R9 | >10 |
| Voltage | 24 V |
| LED type | 2022 |
| LEDs/m | 140 |
| Pitch | 7.14 mm |
| Beam angle | 120° |
| Minimum cut | 50 mm |
| Roll length | 5 / 30 m |
| Lifetime | 50,000 h |
| Ambient temperature | -20 ~ 50 °C |
| Storage temperature | -40 ~ 80 °C |
| Tc point marking | Yes(1) |
| Warranty | 8 years |
| Dimmable | Yes |
| Heat sink required | No |
| Maximum length | 10 m(2) |
| (1) (UNE-EN 60598-1:2015; UNE-EN 60598-2-1:1993) |
| (2) Connected in series |
